Bluetooth module SRRC certification process

SRRC certification service introduction:

China Model Approval is abbreviated as SRRC certification, which is a national compulsory certification, which aims to distinguish the civilian band from the military band in the wireless band. It is the technical management of the technical parameters of the spectrum parameters before the radio transmission equipment is put into use in the development, production, import, purchase and other links. From June 1, 1999, the radio component products sold and used in China must obtain the radio model approval certification. The domestically produced, sold and used radio transmission equipment must be subject to type approval, and the approval certificate and type approval code shall be issued. The type approval code shall be indicated on the label of the factory equipment.

Documents required for Bluetooth module application for SRRC

1. Application form (two copies);

2. Power of attorney (two copies);

3. The customer's business license (Business license);

4. The number of prototypes depends on different products. Three to five sets of RF cables (ie RF port or SMA port) are required;

5. The customer's ISO certificate or company profile and company capability description;

6. Product specifications, circuit diagrams, instructions, block diagrams, operating instructions, etc.;

7. Antenna Peak Gain and Antenna pattern;

8. Test direction (Test direction);

9. The company's business license (annual inspection cannot expire);

10. 3 color photos of EUT (must include each interface and each side);

11. Frequency channel comparison table (only if there are many working channels, such as DSSS or FHSS products);

Documents required for SRRC certification of Bluetooth module:

1. The application form for the approval of the model of radio transmission equipment requires the signature and seal of the enterprise legal person

2. The power of attorney for approval of the radio transmission model requires the signature and seal of the corporate legal person

3. Instruction manual, technical manual, circuit schematic diagram, PCB board diagram, bit number diagram

4. RF line attenuation description, antenna gain description

5. Driver and software (if you need to provide computer control, please provide)

6. Equipment photos (6 photos, front and back of the main board, remove the shielding cover, reflect the application unit, equipment name, equipment model, equipment serial number, structure size, CMIIT ID

7. The corporate legal person's business license needs a seal, and the company's briefing (production capacity, technical strength, quality control) needs a seal

8. The copy of the quality management system certificate is the ISO certificate, and the annual production situation of the radio enterprise (not required by Guangdong and foreign enterprises)

What is the process of Bluetooth module SRRC certification?

1. Submit an SRRC certificate application

2. Application review

3. If qualified, accept the application and designate a test institution

4. Type testing by the testing organization

5. Submit test report

6. Review the test report

7. If qualified, issue SRRC certificate.
